NOMADA 12V105AH

ELECTRICAL SPECIFICATIONS Nominal capacity-105Ah Open circuit voltage-13.2V Self-discharge-<3% per month Cycle life->3500 cycles (100% DoD) Voltage-12V MECHANICAL SPECIFICATIONS Dimensions (LxWxH)- 437 x 90 x 175 mm / 17.2” x 3.5” x 6.9” Weight- 10 kg / 22 lbs Case material- PC-ABS | UL94-V0 Ingress protection- IP66 Cell type / Chemistry- Prismatic - LiFePO4 CHARGE & DISCHARGE SPECIFICATIONS Charge method: CCCV Charge voltage: 14.3V - 14.6V Max. charge current: 105A End of discharge voltage: 10V Discharge current continuous: 105A Discharge pulse current: 315A (30 sec) TEMPERATURE SPECIFICATIONS Charge temperature:0°C to 55°C / 32°F to 131°F Discharge temperature: -20°C to 55°C / -4°F to 131°F Storage temperature: -20°C to 45°C / -4°F to 113°F
